Water Well Borehole Drilling Rig Mini--E80&100 (Electricity)

  • Water Bore Hole Drilling Machine Diy
Water Bore Hole Drilling Machine Diy

Water Bore Hole Drilling Machine Diy

  • Type: Water Bore Hole Drilling Machine Diy
  • Brand Name: HT
  • Certificate: CE
  • Description: HT is a professional manufacturer for water hole drilling machine, water bore drilling diy.
  • INQUIRY   EMAIL

Water Bore Hole Drilling Machine Diy:

HT is a professional manufacturer for water hole drilling machine, water bore drilling diy.

Water Hole Drilling Machine:

Model E80 E100
Principle Positive Cycle Positive Cycle
Electricity Single Phase Three Phases
Drive Motor 2kw (60V DC) 3kw
Lift Mtor 1.5kw (60V DC) 1.5kw
High Pressure Submerged Pump 2.2kw 2.2kw
Max Drilling Depth 80m 100m
Max Drilling Diameter 200mm 400mm
Drilling Pipe 42mm diameter, 1.5m/piece 50mm diameter, 1.5m/piece
Drilling Pipe Equipped 50m 50m
Drilling Bit Equipped 2 pieces 2 pieces
One small bit (60mm,90mm) + one big bit (160-500mm)
Other Parts For One Complete Machine High pressure submerged pump-1 unit
High pressure water pipe-5m
Voltage transformer(change 220V AC to 60V DC)
Only used for E80-P1 model
Tools, seat, oil seal, English manual, etc


Electric water well drilling machine:

100m Electric Water Well Drilling Rigs Machines


Water Bore Drilling Diy:

Water Bore Hole Drilling Machine Diy


E80 E100 water bore drilling diy working video.


We also have diesel hydraulic DH150 water hole drilling machine:

water well drilling rig


DH150 water hole drilling machine working video in Youtube:


We also have big DH200 water bore hole drilling rig:

water well drilling rig


DH200 working video in Youtube:
