Small Core Drilling Rig Machine Man Portable QZ-20

  • Small Portable Core Drilling Machine Manufacturer In China
Small Portable Core Drilling Machine Manufacturer In China

Small Portable Core Drilling Machine Manufacturer In China

  • Function: Core Sample Drilling
  • Type: Small Portable Core Drilling Machine
  • Brand Name: HT
  • Model Number: GC-20
  • Description: Choose manufacturer HT, drilling Diameter (mm): 46/60/75, drilling Pipe Diameter (mm): 32 rotation Speed (r/min): 360/720.
  • INQUIRY   EMAIL

Small Portable Core Drilling Machine:

HT is a professional manufacturer for portable core drilling machine, small core drill machine.

1 Applications Of portable core drilling machine:

GC-20 portable core drilling machine is a portable multi-purpose engineering rig, is suitable for industrial and civil buildings, geophysical pilot holes in bridges, railways,highways, hydropower and other industries.
Our portable core drill machine also used in advanced drilling, grouting and punching, pre-embedded pilot holes, blasting holes, inspection holes, small household wells, etc.

2 Features Of Small Core Drilling Machine :

Compact structure, small size, light weight, high and low gear shifting, easy to move.

3 Technical Parameters Of Small Core Drill Machine:

Drilling Diameter (mm) 46/60/75
Max Drilling Depth (m) 46mm—20m, 60mm—10m, 75mm—8m
Drilling Pipe Diameter (mm) 32
Rotation Speed (r/min) 360/720
Torque (n.m) 82 at 360r/min rotation speed
41 at 720r/min rotation speed
Power (kw) 3Kw(electric motor) or 6.5Hp(gasoline engine)
Weight (kg) 90
Dimension (length x width x height) (mm) 700x650x1950

Portable core drill machine:

portable core drilling machine


small core drilling machine

small core drill machine


QZ20 Portable Core Drilling Machine Video.


Small Core Drilling Machine LHC100 Model:

Working Way hydraulic, two hydraulic systems, hydraulic transmission
Power Source diesel powered
Power 25 Hp
Max Drilling Depth 100 m
Max Drilling Diameter 200 mm
Drilling Angle 0°-90 °
Rotation Speed 0-300 r/min (continuously variable transmission)
Max Torque 600 Nm
Max Lifting Force 3 T
Machine Height 2.6 m
Weight 500 kg
Dimension (length x width x height) 1400 x 1250 x 2600 mm

Portable Core Drill Machine LHC100 Model:

Core Sample Drilling Testing Rig Machine


LHC100 Small Core Drill Machine Video:


Portable core drilling machine is compact and lightweight tools used in industries like geology, construction, and environmental research.
Portable core drill machine is designed for easy transport and operation in remote areas.
Small core drilling machine drill precise holes in materials like rock and soil, offering adjustable parameters for different drilling needs.
With sturdy construction and ergonomic design, they're efficient and maneuverable, making them ideal for fieldwork.
Small core drill machine extract core samples accurately, aiding geological and construction projects.
Overall, they're essential for exploration and research in diverse environments.
